Shikino AI Camera Solutions: Core Features and Applications
Shikino's AI camera solutions provide advanced embedded vision AI technology that is ideal for industrial, healthcare, and security applications. These intelligent cameras are designed to leverage Renesas RZ/V2L processors, enabling rapid and efficient AI processing on edge devices. By integrating Shikino’s intelligent camera modules, businesses can deploy AI-powered solutions for tasks such as head counting, gesture recognition, and anomaly detection.
Renesas RZ/V2L Processor: The camera modules use Renesas's original AI accelerator, "DRP-AI," which enables highly efficient AI processing without significant power dissipation.
Customisable Lens and Interface Options: Shikino offers a wide variety of lens solutions and supports multiple interface options, including USB, wired LAN, wireless LAN, and Power over Ethernet (PoE).
Wide Range of AI Applications: Shikino’s AI SDK allows for easy integration of AI applications, such as head counting, fall detection, gaze analysis, and gesture recognition.
AI Vision Technology with Shikino AI Camera Solutions
Shikino’s intelligent cameras are built to handle a variety of AI-based tasks, providing an embedded solution for industries that require real-time vision AI processing.
Efficient AI Processing: The integrated Renesas DRP-AI accelerator ensures low-latency AI inference, allowing the camera to perform AI-based tasks like fall prevention and facial recognition in real time.
Modular Design: These cameras are equipped with flexible, modular hardware, enabling easy integration into existing systems. The modular interface boards support LTE, PoE, and USB connections, providing multiple communication options.
Custom AI SDK: Shikino’s AI SDK simplifies the development process, providing pre-built AI applications that allow businesses to quickly implement complex vision AI tasks such as human counting and gesture detection.
Key Specifications of Shikino AI Camera Solutions
The technical specifications of Shikino's AI cameras, powered by the Renesas RZ/V2L processor, highlight their robustness and versatility in various environments:
Example Product Number: KBCR-iC41MG
Image Sensor: 1/4” 1.2 MP Rolling Shutter Colour Sensor
Image Output: 1280 x 960 YUV Colour
Storage: 16 GB eMMC
Processor:
CPU: Dual-core Arm® Cortex®-A55 (1.2 GHz)
Additional Core: Arm® Cortex®-M33 (200 MHz)
AI Accelerator: DRP-AI (Dynamic Reconfigurable Processor for AI inference)
GPU: Integrated GPU core for graphics processing
Video Codec: H.264 codec for efficient video compression
Interface Options:
UART / USB 2.0 (OTG) / GPIO
Extended Interface (Optional): USB (HOST), SPI, I2S, SD, GPIO, RMII, RGMII
PCB Size: W: 50 mm x D: 50 mm x H: 15.2 mm (without optics)
Operating Temperature Range: -10°C to +60°C, making these cameras suitable for harsh industrial environments.
Applications of Shikino AI Cameras
Shikino's AI camera solutions are well-suited for a variety of industries, particularly those requiring real-time visual processing. Here are some example use cases:
Industrial Automation and Monitoring: Use AI-powered cameras to detect anomalies in production lines and optimise processes through human counting and gesture recognition.
Healthcare and Fall Prevention: AI applications such as fall detection and gaze analysis enhance safety in hospitals, nursing homes, and other healthcare environments.
Security and Surveillance: Embedded AI vision in surveillance cameras enables tasks like suspicious person detection, facial recognition, and gate security for enhanced safety and monitoring.
Development Tools and Ecosystem
Shikino provides a comprehensive development ecosystem to support rapid integration of their AI camera solutions:
AI SDK: Shikino’s AI SDK supports a wide range of AI applications, and is integrated with the Renesas RZ/V2L processors to simplify the implementation of complex AI algorithms.
Multiple Communication Interfaces: Wired and wireless communication options (LAN, PoE, USB, LTE) ensure seamless integration into different system architectures.
Customisable Hardware: With modular interface boards and a variety of lens options, these cameras can be tailored to meet specific project needs across different industries.
Conclusion
Shikino’s AI camera solutions offer advanced, embedded vision AI processing for a wide range of applications, including industrial automation, healthcare, and security. With the integration of Renesas RZ/V2L processors, modular interface options, and pre-built AI applications, Shikino’s cameras provide a versatile and efficient solution for businesses looking to enhance their systems with real-time AI capabilities.
